1
Engine displacement
650
2
Model
MOTO-65
3
Year
1998
4
Trim
MOTO' 6.5
5
Parts Catalog
Oil pump
6
Parts Diagram
Parts Catalog
Gear box
by
Clutch cover
Oil pump
1
1
2
3
4
4
4
4
4
5
6
7
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
54
54
54
54
54
54
55
56
56
56
1
Crankcase assy
AP0295166
Not Available
2
Bush 48x52x22,8
AP0233675
Not Available
3
Bush 48x52x22,8
AP0233680
Not Available
4
Pin M8x12
AP0632010
Not Available
5
Pin M6x50
AP0229301
Not Available
6
Pin 5x10
AP0929650
Not Available
7
Bush
AP0247320
Not Available
8
Oil seal 15x24x7
AP0430550
Not Available
9
Oil seal 25x40x7
AP0230395
Not Available
10
Bearing 6305
AP0932826
Not Available
11
Bearing 6303 E-RS1
AP0232501
Not Available
12
Bearing 6205
AP0232764
Not Available
13
Bearing 6303 ETN9
AP0932815
Not Available
14
Oil strainer
AP0256321
Not Available
15
Plate
AP0256430
Not Available
16
Special TE screw
AP0941925
$3,65 Unit Price incl. VAT
17
Gasket
AP0250910
Not Available
18
Ball
AP0932830
Not Available
19
Compression spring 13,5
AP0239280
Not Available
20
Valve closer screw
AP0256170
Not Available
21
Hex socket screw
AP0241822
Not Available
22
Hex socket screw
AP0241810
Not Available
23
Hex socket screw
AP0240531
Not Available
24
Hex socket screw
AP0241262
Not Available
25
Circlip 10x1
AP0245330
$3,65 Unit Price incl. VAT
26
Pin 4x15,8
AP0232730
Not Available
27
Internal and external rotor
AP0956277
Not Available
28
Internal and external rotor
AP0256347
Not Available
29
Oil pump cover
AP0210640
Not Available
30
screw
AP0940516
Not Available
31
Thrust washer 10,1/17/1
AP0827590
$4,82 Unit Price incl. VAT
32
Pin
AP0232430
Not Available
33
Oil pump gear Z=25
AP0234560
Not Available
34
Joint m12x1,5
AP0256330
Not Available
35
Gasket
AP0552280
$7,23 Unit Price incl. VAT
36
Magnetic drain plug m18x1,5
AP0840277
Not Available
37
Gasket ring 8x13
AP0950141
Not Available
38
Hex socket screw
AP0440193
Not Available
39
Spacer 6,2x10x14,5
AP0247790
Not Available
40
Hex screw
AP0941500
Not Available
41
Free pinion shaft
AP0237060
Not Available
42
Oil anti-return valve
AP0260570
$6,38 Unit Price incl. VAT
43
Valve pin
AP0256150
Not Available
44
Spring
AP0239810
Not Available
45
Valve closer screw
AP0256170
Not Available
46
Oil filter
AP0256185
$21,87 Unit Price incl. VAT
47
O-ring 60x2,5
AP0230920
$3,65 Unit Price incl. VAT
48
Oil filter cover
AP0210411
Not Available
49
Hex socket screw
AP0241932
Not Available
50
Oil pressure switch
AP0956169
Not Available
51
Sensor
AP0640190
Not Available
52
Stud bolt M10x78
AP0240545
$7,94 Unit Price incl. VAT
53
Stud bolt M10x62
AP0240541
Not Available
54
Loctite (violet) 221 10cc.
AP0899785
Not Available
55
Loctite (orange) 574
AP0899784
Not Available
56
Molykote G-N 50gr.
AP0297433
Not Available

Find the detailed :label APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
