EXHAUST PIPE I FOR APRILIA TUONO V4 RR 2016

Foot rests

Item numbers

FRONT. EXHAUST PIPE

858738

Contact

FLANGED NUT M7X1 H=8
NUT

436947

$3,38

Unit Price

PACKING SILENCER/HEAD
EXHAUST PIPE GASKET

852090

$6,54

Unit Price

EXHAUST PIPES SPRING
SPRING

AP8121170

$17,07

Unit Price

CENTRAL EXHAUST MANIFOLD
EXHAUST PIPE CYLINDER

899987

85224R

$1 926,14

Unit Price

LAMBDA SENSOR
LAMDA SENSOR L. 325 MM

584344

$93,68

Unit Price

GASKET

GU05128230

$53,16

Unit Price

MUFFLER PIPE CLAMP
HOSE CLAMP D 57 MM

2B003044

$18,12

Unit Price

CLAMP
LH MANIFOLD PIPE D 63 MM

851586

$12,68

Unit Price

EXHAUST PIPE CYLINDER

858739

8587396

$202,79

Unit Price

LH REAR EXHAUST PIPE

858740

Contact

SILENCER

2B003035

Contact

SILENCER

B043283

Contact

HOSE CLAMP D 57 MM
MUFFLER PIPE CLAMP

2B002264

2B003044

$18,12

Unit Price

HEAT PROTECTION
EXHAUST PIPE HEAT PROT.

898383

$110,04

Unit Price

SOCKET-HEAD FLANGED M6X10 TORX SCREW
TORX SCREW M6X10

898385

$0,38

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

CURVED SPRING WASHE 8, 4X15X0, 8
WASHER 8, 5X15X0, 8

AP8150376

$3,30

Unit Price

HEX SOCKET SCREW M8X35

AP8150236

$3,30

Unit Price

BUSH

AP8121199

$7,23

Unit Price

RUBBER SPACER

AP8144558

$4,38

Unit Price

SPACER BUSH

AP8121455

$3,65

Unit Price

WASHER 8.5X24X2 DA UNI 6593 R40
WASHER

AP8150018

Contact

NUT M8 -UNI 7474-INOX A2-70
LOW NUT M8

AP8150431

$3,30

Unit Price

LOWER FAIRING FIXING BRACKET
FIXING BRACKET

2B001525

$31,21

Unit Price

CROSS RR TUBE
BRACKET

899332

$18,54

Unit Price

SCREW W/ FLANGE
SCREW

AP8152278

598839

$0,09

Unit Price

SILENT-BLOCK

894228

$6,69

Unit Price

WASHER 8.5X24X2 DA UNI 6593 R40
WASHER

AP8150018

Contact

HEX SOCKET SCREW M8X12
HEX SOCKET SCREW

AP8152112

$3,65

Unit Price

SERVOMOTOR
EXHAUST VALVE ACTUATOR

2D000064

$667,51

Unit Price

HEAT PROTECTION

890928

$1,91

Unit Price

FLANGED HEXAGONAL HEAD SCREW M6X30
SCREW W/ FLANGE M6X30

AP8152281

$3,30

Unit Price

AIR BOX SPACER

AP8134640

$3,65

Unit Price

T BUSH
T BUSH *

AP8121725

$3,65

Unit Price

GROMMET
RUBBER SPACER *

AP8120223

$5,38

Unit Price

SPACER

840509

$0,48

Unit Price

CABLE
GAS TRASMISSION RETURN

B045008

$36,15

Unit Price

CABLE
GAS TRASMISSION DELIVERY

B045009

$33,74

Unit Price

CLAMP
HOSE CLAMP

845978

$3,07

Unit Price

COVER
EXHAUST VALVE ACTUATOR COVER

899524

$4,40

Unit Price

SPACER BUSH
SPACER

AP8120253

$3,65

Unit Price

SCREW
SCREW W/ FLANGE M6X35

AP8152282

$3,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
