Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Saddle

STEERING FOR APRILIA TUONO V4 1100 RF E4 ABS 2018

Swing arm

Item numbers
Steering Aprilia APRILIA-MOTORCYCLES 1100 TUONO 2018 Tuono V4 1100 RF E4 ABS
1
2
2
2
3
3
4
5
6
7
8
9
10
11
12
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
CPL. LOWER PLATE
LOWER FORK PLATE

2B003925  

Unit Price

2
HEX SOCKET SCREW M8X35

AP8150236  

Unit Price

3
DUST COVER RING

AP8123641  

Unit Price

4
AXIAL BALL BEARING

AP8110077  

Contact
5
FLANGED HEXAGONAL HEAD M8X25 DA -8.8
SCREW W/ FLANGE M8X25

AP8152287  

Unit Price

6
STEERING DUST RING
DUST COVER RING

AP8123644  

Unit Price

7
RING NUT

AP8123642  

Unit Price

8
STEERING SECURITY PLATE

AP8121207  

Unit Price

9
RETURN RING NUT

AP8123643  

Unit Price

10
HEX SOCKET SCREW M10X30

AP8150195  

Unit Price

11
SHEAR RIVET M8 X 28 D.B.
SHEAR RIVET M8X28

AP8152238  

Unit Price

12
TCC INOX SCREWS M8 X 30
SCREW

AP8150540  

Unit Price

13
FORK UPPER SUPPORT
FORK UPPER PLATE

2B003976  

Unit Price

14
STEM PLUG WASHER

AP8152384  

Unit Price

15
UPPER PLATE FIXING BUSH

AP8121346  

Unit Price

16
HANDLEBAR LOWER CLAMP
LOWER U-BOLT

2B003986  

Unit Price

17
HANDLEBAR UPPER CLAMP
UPPER U-BOLT

2B003980  

Unit Price

18
TCC INOX SCREWS M8 X 30
SCREW

AP8150540  

Unit Price

19
WASHER 8, 4X13*

AP8152154  

Unit Price

20
FAIRLEAD

B044620  

Unit Price

21
DISK COVER BUSH
T BUSH 8, 2X12X4

AP8121096  

Unit Price

22
WASHER 8, 4X16X1, 6-ISO 7089 DA R40
WASHER 8, 4X16X1, 6

AP8150017  

Unit Price

23
HEXAGON COCKET SCREWS M6X30 Z.N.
HEX SOCKET SCREW M6X30

AP8152128  

Unit Price

24
KNURLED SPRING WASHER
WASHER 6, 4X10X, 7*

AP8152105  

Unit Price

25
STEERING SHOCK ABSORBER

2B001706  

Unit Price

26
T BUSH

AP8121811  

Unit Price

27
SPACER

2B002151  

Unit Price

28
CURVED SPRING WASHE 8, 4X15X0, 8
WASHER 8, 5X15X0, 8

AP8150376  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
