CENTRAL ELECTRICAL SYSTEM FOR APRILIA CAPONORD RALLY 2017

Item numbers

CABLE HARNESS

2D000001

Contact

FUSE HOLDER BOX

894603

$22,89

Unit Price

FUSE
FUSE 10A

CM225610

$6,53

Unit Price

FUSE
FUSE 7, 5A

CM225607

$5,00

Unit Price

FUSE
FUSE 15A

CM225615

$5,00

Unit Price

ELECTRIC DEVICE BRACKET
CABLE DUCT COVER

B046225

$7,83

Unit Price

ELECTRIC DEVICE BRACKET
CABLE DUCT BASE

B046226

$6,35

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

PLUG
RUBBER SPACER

AP8120712

$4,38

Unit Price

RELAIS SUPPORT

AP8124293

$5,38

Unit Price

RELAY
RELAY 20A

895907

$5,40

Unit Price

SCREW FOR PLAST. 5X14 T1/2T WITH FL.
SELF-TAP SCREW 5X14

AP8150509

$3,30

Unit Price

DEMAND SENSOR
ACCELERATOR POSITION SENSOR

B044414

$708,55

Unit Price

SCREW FOR PLAST. 5X14 T1/2T WITH FL.
SELF-TAP SCREW 5X14

AP8150509

$3,30

Unit Price

RUBBER TOP
RUBBER SPACER

854811

$0,92

Unit Price

SUPPORT DEMAND
SUPPORT BRACKET

2B000128

$10,76

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

GROMMET
RUBBER SPACER

AP8120030

$4,38

Unit Price

WASHER 15X5, 5X1, 2

AP8150382

$3,65

Unit Price

SCREW
PHILLIPS SCREW, SWP M5X20

AP8152329

$3,30

Unit Price

ECU CASE BASE
HOLDER

2B000149

$19,68

Unit Price

ECU CASE COVER
CONTROL UNIT COVER

2B000148

$26,13

Unit Price

ELETTRONIC INJECTOR DEVICE
ELECTRONIC INJECTION DEVICE

CM228232

$1 437,08

Unit Price

PLUG
RUBBER SPACER

AP8120712

$4,38

Unit Price

GROMMET
RUBBER SPACER

AP8120030

$4,38

Unit Price

T BUSH

AP8221023

$3,30

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

SCREW
SCREW W/ FLANGE M6X20

AP8152279

$3,30

Unit Price

SCREW
SCREW W/ FLANGE M6X35

AP8152282

$3,65

Unit Price

/
SPACER

AP8221017

$3,65

Unit Price

FLY SPRING
INSTRUMENT SUPPORT

890760

$4,86

Unit Price

RELAY
RELAY 12V-30A

AP8224462

$12,61

Unit Price

SUPPORT RELAY'
RELAIS SUPPORT

2B000115

$23,22

Unit Price

SCREW
PHILLIPS SCREW, SWP M5X20

AP8152329

$3,30

Unit Price

ELECTRIC DEVICE BRACKET
ROTATING SENSOR COVER

B046008

$18,44

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

M.I.U. INPUT DEVICE
ROTARY SENSOR

B045399

$410,38

Unit Price

ELECTRIC DEVICE BRACKET
SENSOR SUPPORT

B046007

$17,07

Unit Price

HEX SOCKET SCREW
HEX SOCKET SCREW M5X12

AP8152267

$3,65

Unit Price

CURVED SPRING WASHER 5.5X10X0.5
CURVED SPRING WASHER 5, 3X10X0, 5

AP8150272

$3,65

Unit Price

SWING ARM COMPLETE
REACTION ROD ASSY.

B046023

$42,72

Unit Price

ARICULATED JOINT
LEFT BALL JOINT M6

898397

$20,03

Unit Price

ARICULATED JOINT
RH BALL JOINT M6

898396

$19,55

Unit Price

NUT M6

AP8150026

$3,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Central electrical system of your Aprilia Caponord Rally of CAPONORD. Let us know if you have any questions.

Choose the exact model of your Aprilia CAPONORD 1200 to access the different categories of genuine spare parts
