DRIVE SHAFT FOR APRILIA AF1 FUTURA 1991

Body

Item numbers
Drive shaft Aprilia APRILIA-MOTORCYCLES 125 AF1 1991 AF1 FUTURA
1
2
3
3
3
3
4
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
23
23
24
24
25
26
26
27
28
28
28
28
29
30
30
1
CRANKSHAFT CPL.

AP0293846  

Contact
2
SPACER

AP0827410  

Contact
3
THRUST WASHER 0, 3 MM

AP0944582  

Contact
3
THRUST WASHER 0, 1 MM

AP0944583  

Unit Price

3
THRUST WASHER 0, 5 MM

AP0944584  

Contact
3
THRUST WASHER 0, 2 MM

AP0944586  

Contact
4
BEARING 6206
BEARING 6206

AP0932588  

AP0832533

Unit Price

5
BREAK WASHER A12

AP0945754  

Contact
6
NUT M12X1

AP0642051  

Contact
7
O-RING 18X3, 5

AP0430460  

Unit Price

8
BALANCE SHAFT GEAR Z=27

AP0234431  

Unit Price

9
TRANSMISSION KEY 3X3, 7

AP0246055  

Contact
10
PRIMARY TRANSM.

AP0293926  

Contact
11
WASHER

AP0945756  

Contact
12
NUT

AP0242570  

Contact
13
STARTING SHAFT L=103 MM

AP0237900  

Contact
14
THRUST WASHER 10, 1/17/1

AP0827590  

Unit Price

15
INTERMEDIATE GEAR Z=34

AP0234405  

Contact
16
BEARING 6302

AP0232291  

Contact
17
BALANCE SHAFT

AP0237945  

Contact
18
BALL BEARING 6005

AP0232340  

Contact
19
THRUST WASHER

AP0227280  

Unit Price

20
SCREW

AP0940315  

Contact
21
SEEGER 25X1, 2

AP0945810  

Contact
22
ROLLER CAGE 15X19X20

AP0932028  

Unit Price

23
PISTON ASSY 54, 00 MM

AP0294757  

Contact
23
PISTON ASSY 53, 99

AP0295346  

Contact
23
PISTON ASSY 53, 98 MM
PISTON ASSY 53, 98 MM

AP0295345  

AP0294744

Unit Price

24
RING D54
RING D54

AP0215825  

AP0215672

Unit Price

25
PISTON PIN

AP0216139  

Contact
26
STOP RING D15

AP0945635  

Unit Price

27
CONNECTING ROD CPL.

AP0295374  

Contact
28
LOCTITE ANTI SEIZE 50ML.15378

AP0297434  

Contact
29
LOCTITE (GREEN) 648 5GR.

AP0899788  

Contact
30
LOCTITE (VIOLET) 221 10CC.

AP0899785  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Drive shaft of your Aprilia AF1 FUTURA of AF1. Let us know if you have any questions.
