Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Cylinder head

ENGINE FOR APRILIA LEONARDO ST 2002

Carburettor I

Item numbers
Engine Aprilia APRILIA-SCOOTER 125 LEONARDO 2002 Leonardo ST
1
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
ENGINE, COMPLETE 120

AP8106847  

Contact
1
COMPLETE ENGINE, WATER COOLED

AP8106848  

Contact
1
ENGINE, COMPLETE 120

AP8106930  

Contact
1
ENGINE, COMPLETE 120

AP8176029  

Contact
1
COMPLETE ENGINE, WATER COOLED

AP8176030  

Contact
2
GROMMET
RUBBER SPACER

AP8120030  

Unit Price

3
VARIATOR COOLING FILTER

AP8102522  

Unit Price

4
VARIATOR AIR INTAKE, BLACK

AP8149603  

Contact
5
SHOCK ABSORBER
SHOCK ABSORBER PAIOLI

AP8123877  

Unit Price

6
HELMET HOLDER HOOK

AP8221206  

Unit Price

7
SELF-LOCKING NUT M8*
SELF-LOCKING NUT M8

AP8152300  

Unit Price

8
SCREW W/ FLANGE M8X35
SCREW W/ FLANGE

AP8152289  

Unit Price

9
SCREW W/ FLANGE M8X40

AP8152290  

Unit Price

10
CABLE-GUIDE

AP8221172  

Unit Price

11
WATER COOLER FILTER SUPPORT

AP8138938  

Contact
12
T BUSH

AP8121266  

Unit Price

13
T BUSH
T BUSH *

AP8121725  

Unit Price

14
REAR BLACK MUDGUARD SUPPORT

AP8134362  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Engine of your Aprilia Leonardo ST of LEONARDO. Let us know if you have any questions.
