COOLING SYSTEM FOR APRILIA SR MAX 2013

Side cover - Spoiler

Item numbers

WATER TANK
TANK

975031

Contact

FILLER CAP
EXPANSION TANK PLUG

623673

$4,85

Unit Price

O-RING FOR FILLER CAP
FUEL TANK GASKET

620737

$4,82

Unit Price

DELIVERY RADIATOR/COOLING TANK PIPE
TANK-COOLER FEED PIPE

CM007007

$20,60

Unit Price

CLAMP
HOSE CLAMP

CM001914

$3,30

Unit Price

TUBE
COOLER-TANK RETURN PIPE

975696

$3,23

Unit Price

CLAMP
HOSE CLAMP

CM001921

$3,65

Unit Price

STIRRUP NEXUS
BRACKET

975592

$2,58

Unit Price

SCREW
TBCIC SCREW

270793

$2,74

Unit Price

BUFFER
LOWER RUBBER

258904

$5,53

Unit Price

ELECTRIC FAN ASSY.
ELECTRIC FAN

58170R

58211R

$148,33

Unit Price

METRICAL SCREW
SCREW M6X16

CM179301

$3,65

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

RADIATOR X9
WATER COOLER

57311R

$93,31

Unit Price

SCREW
METRIC SCREW M6X20

259830

$0,09

Unit Price

WASHER
WASHER D6, 2X20X1

013092

$2,95

Unit Price

SPACER

273288

$3,65

Unit Price

BUFFER
UPPER RUBBER

351782

$5,53

Unit Price

BUFFER
LOWER RUBBER

258904

$5,53

Unit Price

PLUG B500
COVER

621365

$4,82

Unit Price

PACKING
COPPER GASKET

168077

$3,65

Unit Price

PUMP RADIATOR JOINT PIPE

655644

$34,93

Unit Price

CYLINDER-HEAD RADIATOR JOINT PIPE

654154

$23,82

Unit Price

CLAMP
HOSE CLAMP

CM001915

$3,65

Unit Price

RETAINING STRAP
LOCK-STRAP L=277

257134

$0,09

Unit Price

CLAMP (D.30.1 S.0, 6 L.7)
HOSE CLAMP

CM001922

$3,65

Unit Price

PIPINGS RETAINING SPRING
PIPES/CABLES RETAINER SPRING

CM006903

$5,38

Unit Price

SCREW W/ FLANGE M6X16
FLANGED HEXAGONAL SCREW M6X16

434541

B016777

$3,65

Unit Price

STIRRUP WITH I.P.

656004

$4,98

Unit Price

CONVEYOR

654220

$3,18

Unit Price

PLAIN WASHER
WASHER 4, 5X12X1

016670

$2,95

Unit Price

RIVET

252099

$3,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
