Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Central body - Tunnel

CENTRAL SEMI-CRANKCASE FOR APRILIA LEONARDO ST 2001

Crankcase

Item numbers
Central semi-crankcase Aprilia APRILIA-SCOOTER 150 LEONARDO 2001 Leonardo ST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
15
16
17
18
19
20
21
22
23
1
BEARING 6003-2RS

AP0232621  

Contact
2
BEARING 6302

AP0232291  

Contact
3
BALL BEARING

AP0932425  

Contact
4
OIL SEAL 30X52X7

AP0930900  

Contact
5
SLEEVE CRANKCASE

AP0260295  

Contact
6
PLUG M14X1, 5
COVER M14X1, 5

AP0241660  

Unit Price

7
O-RING 14X3, 2

AP0650350  

Contact
8
COVER M12X1, 5

AP0841921  

Contact
9
GASKET RING 12X18

AP0250640  

Contact
10
OIL FILTER
OIL FILTER

AP0256450  

AP0256451

Unit Price

11
OIL FILTER COVER
OIL FILTER COVER

AP0211500  

AP0211506

Unit Price

12
O-RING

AP0430920  

Unit Price

13
HEX SOCKET SCREW M6X30

AP0840880  

Unit Price

14
GASKET

AP0650182  

Unit Price

15
HEX SOCKET SCREW M6X80

AP0241501  

Contact
16
OIL PRESS VALVE BODY
OIL PRESS VALVE BODY

AP0256482  

AP0256483

Unit Price

17
GASKET RING 6X10

AP0230415  

Contact
18
HEX SOCKET SCREW M6X30

AP0840880  

Unit Price

19
GASKET RING 16X22

AP0430622  

Contact
20
COVER M16X1, 5

AP0240230  

Contact
21
HEX SOCKET SCREW M6X60

AP0240371  

Contact
22
BALL 8, 5 MM

AP0432680  

Unit Price

23
COMPRESSION SPRING 13, 5

AP0239280  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Central semi-crankcase of your Aprilia Leonardo ST of LEONARDO. Let us know if you have any questions.
