IGNITION UNIT II FOR APRILIA ATLANTIC 2006

Oil breather valve

Item numbers

FLYWHEEL COVER CPL.
FLYWHEEL SIDE COVER ASSY

AP8176320

8798315

$256,68

Unit Price

WATER PUMP SHAFT ASSY.
PUMP SHAFT

AP8176393

8447595

$16,29

Unit Price

GASKET RING
WATER PUMP SEAL RING

AP8590055

82991R

$21,71

Unit Price

WATER PUMP IMPELLER CPL.
ROTOR

AP8276091

844730

$3,01

Unit Price

PUMP IMPELLER DRIVE KEY
COUPLING ENTRAINER

AP8577014

842389

$5,64

Unit Price

BEARING 28X8X9
BEARING X9 250

AP8577012

82755R

$14,18

Unit Price

GASKET RING 20X30X5
GASKET RING 20.30.5

AP8577013

82897R

$4,36

Unit Price

COMPLETE ROTOR (KOKUSAN)
ROTOR ASSY WITH HUB

AP8176334

639385

$117,45

Unit Price

STATOR
STATOR ASSY

AP8176335

58070R

$152,55

Unit Price

WATER PUMP COVER
WATER PUMP COVER WITH I.P.

AP8176287

877528

$14,43

Unit Price

SCREW M6X14
SCREW VITE TCCIC M6X14 UNI 7687

AP8577048

008375

$1,55

Unit Price

PUMP-CYLINDER HOSE
PIPE FOR WATER COOLED

AP8580277

878626

$5,38

Unit Price

FLYWHEEL ASSY.
COMPLETE FREEWHEEL

8477975

$71,50

Unit Price

HEX SOCKET SCREW M6X24
SCREW HEAD SCREW

847679

877289

$3,65

Unit Price

TRANSMISSION KEY
KEY

AP8560006

000097

$8,01

Unit Price

SPECIAL NUT
SPECIAL HESAGONAL NUT

AP8577043

82952R

$5,90

Unit Price

BREAK WASHER
WASHER SPRING

AP8550487

479515

$0,05

Unit Price

STARTER MOTOR GEAR
INAMOVABLE TOOTHED CROWN ELECTRIC START

AP8570018

82737R

$81,00

Unit Price

TIMING PLUG ASSEMBLY
OIL PLUG

AP8577015

8290405

$10,28

Unit Price

GASKET

AP8550417

Contact

PLAIN WASHER
WASHER

AP8577044

842385

$0,68

Unit Price

SCREW M5X22
CROSS SLOTTED SCREW WITH CYLINDER HEAD

AP8551060

828662

$0,05

Unit Price

RING CONTAINER LAMINATION
SHEET

AP8577049

848724

$0,58

Unit Price

LOW HEAD SOCKET SCREW M6X30
SCREW M6X30 T.C.E.I

AP8560011

122637

$5,20

Unit Price

PLATE

AP8577010

Contact

SCREW M5X10
SCREW FOR OUTER H.T. COIL (M5X10)

AP8560009

018575

$2,95

Unit Price

O-RING
WATER PUMP LEADER O-RING

AP8580084

485080

$0,72

Unit Price

HOSE CLAMP

CM001908

$3,65

Unit Price

DRIVE KEY
SPRING

AP8577037

842390

$0,48

Unit Price

BY-PASS PIPE
"BY-PASS" WATER TUPE

AP8176330

878940

$5,38

Unit Price

HOSE CLAMP
CLAMP

AP8144579

CM001904

$3,65

Unit Price

PLATE

848109

$3,65

Unit Price

SCREW M6X35
HEXAGONAL FLANGED HEAD SCREW(M6X35)

AP8550079

414838

$3,30

Unit Price

SCREW M6X112, 5
FLANGED HEXAGONAL SCREW M6X112.5

AP8176319

B016807

$3,65

Unit Price

BRACKET
BRACKET

AP8154085

639843

$6,30

Unit Price

SCREW W/ FLANGE
FLANGED HEXAGONAL HEAD SCREW

AP8551045

484123

$0,05

Unit Price

WASHER

012528

$2,95

Unit Price

CLAMP (D.30.1 S.0, 6 L.7)
HOSE CLAMP

CM001922

$3,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Ignition unit II of your Aprilia Atlantic of ATLANTIC. Let us know if you have any questions.
