Crank-case

DRIVE SHAFT - CYLINDER - PISTON FOR APRILIA LEONARDO ST (ENGINE YAMAHA) 2001

Engine

Item numbers
Drive shaft - Cylinder - Piston Aprilia APRILIA-SCOOTER 250 LEONARDO 2001 Leonardo ST (engine Yamaha)
1
2
3
4
5
5
5
6
6
6
7
8
8
9
10
11
12
13
1
CYLINDER

AP8122471  

Contact
2
CYLINDER BASE GASKET

AP8122492  

Contact
3
PIN

AP8122558  

Contact
4
CYLINDER HEAD GASKET

AP8122493  

Contact
5
PISTON 0, 5 MM

AP8122571  

Contact
5
PISTON 1, 00 MM

AP8122572  

Contact
5
PISTON

AP8122573  

Contact
6
PISTON RING SET 0, 5 MM

AP8122574  

Contact
6
PISTON RING SET 1, 00 MM

AP8122575  

Contact
6
PISTON RING SET

AP8122576  

Unit Price

7
PISTON PIN

AP8122563  

Unit Price

8
CIRCLIP W. BENT END

AP8122448  

Unit Price

9
TRANSMISSION KEY

AP8122521  

Contact
10
CRANKSHAFT CPL.

AP8122470  

Contact
11
WASHER

AP8122645  

Contact
12
NUT

AP8122526  

Contact
13
PIN D10, 5X14X16

AP8122556  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Drive shaft - Cylinder - Piston of your Aprilia Leonardo ST (engine Yamaha) of LEONARDO. Let us know if you have any questions.
