WATER PUMP FOR APRILIA LEONARDO (ENGINE YAMAHA) 2001

Carburettor II

Item numbers
Water pump Aprilia APRILIA-SCOOTER 250 LEONARDO 2001 Leonardo (engine Yamaha)
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
15
16
17
18
1
WATER PUMP IMPELLER CPL.

AP8122515  

Contact
2
WATER PUMP COVER

AP8122467  

Contact
3
GASKET

AP8122495  

Contact
4
HEX SOCKET SCREW

AP8122411  

Contact
5
BEARING

AP8125822  

Contact
6
WATER PUMP CASING

AP8122512  

Contact
7
OIL SEAL

AP8122539  

Contact
8
MECHANICAL GASKET

AP8122605  

Contact
9
SNAP RING

AP8122437  

Contact
10
GASKET

AP8122487  

Contact
11
HEXAGON COCKET SCREWS M6X35
HEX SOCKET SCREW M6X35

AP8152136  

Unit Price

12
O-RING

AP8144273  

Contact
13
O-RING

AP8144270  

Contact
14
JOINT

AP8122518  

Contact
15
HEX SOCKET SCREW

AP8122410  

Contact
16
SCREW W/ FLANGE

AP8122413  

Contact
17
BRAKE TUBE CABLE GUIDE
CABLE-GUIDE

AP8201417  

Unit Price

18
SCREW
SCREW W/ FLANGE M6X35

AP8152282  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Water pump of your Aprilia Leonardo (engine Yamaha) of LEONARDO. Let us know if you have any questions.
