Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Front headlamps - Turn signal lamps

MAIN CABLE HARNESS FOR APRILIA SR MAX 2013

Rear headlamps - Turn signal lamps

Item numbers

WIRING HARNESS
MAIN WIRING HARNESS

640709

$404,12

Unit Price

CABLE HARNESS
MAIN WIRING HARNESS

680087

$417,04

Unit Price

ELECTRIC CONTROLS MANAGEMENT DEVICE

640963

Contact

PLASTIC CLAMP
LOCK-STRAP L=180MM

145298

$3,38

Unit Price

FUSE 7, 5A

252945

$0,29

Unit Price

LAMELLAR FUSE 15A
FUSE 15A

290860

$0,29

Unit Price

FUSE
REED FUSE 10A

292507

$0,29

Unit Price

FUSE 30A
FUSE

581440

CM225730

$6,53

Unit Price

PIPINGS RETAINING SPRING
NON RETURN SPRING L=23

CM006908

$5,38

Unit Price

PIPINGS BETAINING SPRING
NON RETURN SPRING L=33

CM006906

$5,38

Unit Price

SPRING PLATE

CM017405

$3,65

Unit Price

PLAIN WASHER (4, 2X12X1)
FLAT WASHER 4, 2X12X1

013763

$2,74

Unit Price

SCREW

015728

$2,95

Unit Price

SCREW M6X20
HEX SCREW M6X20

018639

$3,30

Unit Price

PLASTIC CLAMP
LOCK-STRAP L=180MM

145298

$3,38

Unit Price

ELASTIC SUPPORT
FLEXIBLE SUPPORT

291017

$19,68

Unit Price

RETAINING STRAP
LOCK-STRAP L=277

257134

$0,09

Unit Price

GROUND CABLE FOR STARTER MOTOR
GROUND CABLE

584843

$9,18

Unit Price

SCREW
HEX SCREW M6X18

031089

$2,95

Unit Price

GLOVE COMP. SPRING CLAMP
SPRING CLAMP

577594

$4,82

Unit Price

CLIMP
NON RETURN SPRING

CM006902

$5,38

Unit Price

PIPINGS RETAINING SPRING
PIPES/CABLES RETAINER SPRING

CM006903

$5,38

Unit Price

PIPINGS BETAINING SPRING
NON RETURN SPRING L=27

CM006904

$5,38

Unit Price

WIRING LOOM
INSTRUMENT WIRING HARNESS

639764

$19,17

Unit Price

CAP

582172

Contact

CLAMP
HOSE CLAMP

638792

$4,82

Unit Price

CLAMP
HOSE CLAMP

564761

$0,38

Unit Price

WASHER

012528

$2,95

Unit Price

SCREW

125647

$3,68

Unit Price

REMOVABLE CLAMP
HOSE CLAMP

298729

$3,65

Unit Price

METRICAL SCREW WITH CROSS MOULD.
SCREW M6X16

272836

$0,09

Unit Price

WASHER

012528

$2,95

Unit Price

FLANGED HEXAGONAL HEAD SCREW
SCREW W/ FLANGE

484123

$0,05

Unit Price

BRACKET

639843

$6,30

Unit Price

SPRING
CONNECTOR SPRING

584520

$5,38

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

All the genuine spare parts for the Aprilia 2013
