HEAD - CYLINDER - PISTON FOR APRILIA MINI RX EXPERIENCE 2003
Item numbers
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1
CYLINDER WITH PISTON
AP8350210
AP8350210
Contact
2
PISTON
AP8350149
AP8350149
Contact
3
CYLINDER HEAD
AP8350187
AP8350187
Contact
4
NUT
AP8350101
AP8350101
Contact
5
WASHER
AP8350167
AP8350167
Contact
6
STUD BOLT
AP8350154
AP8350154
Contact
7
GASKET
AP8350132
AP8350132
Contact
8
STUD BOLT
AP8350098
AP8350098
Contact
9
WASHER
AP8350162
AP8350162
Contact
10
STUD BOLT
AP8350155
AP8350155
Contact
11
GASKET
AP8350126
AP8350126
Contact
12
O-RING
AP8350079
AP8350079
Contact
13
RING
AP8350179
AP8350179
Contact
14
PISTON PIN D
AP8350180
AP8350180
Contact
15
RING
AP8350069
AP8350069
Contact
16
ENGINE CPL.
AP8350490
AP8350490
Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times. The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible. Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts. Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Head - Cylinder - Piston of your Aprilia Mini RX Experience of MINI-RX. Let us know if you have any questions.
