ELECTRICAL SYSTEM FOR APRILIA RX RACING 2003

Exhaust pipe

Item numbers
Electrical system Aprilia APRILIA-MOTORCYCLES 50 RX 2003 RX Racing
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
MAIN WIRING HARNESS

AP8224585  

Contact
2
BALL 7, 1

AP8201326  

Unit Price

3
FRONT BRAKE SWITCH+HARNESS

AP8212196  

Contact
4
MAIN SWITCH - STEERING LOCK

AP8224548  

Contact
5
HORN

AP8212753  

Contact
6
TIE 4.5X180
BLACK HOSE 178X4

AP8120416  

Unit Price

7
TRANSDUCER

AP8212474  

Contact
8
H.T. WIRING

AP8212212  

Contact
9
BATTERY NEGATIVE LEADS

AP8112573  

Contact
10
SCR. SPARKPLUG CAP

AP8212219  

Contact
11
VOLTAGE REGULATOR

AP8212121  

Contact
12
BATTERY 12V-4AH
YUASA YB4L-B

AP8212110  

234390

Unit Price

13
FLASHER UNIT 12V 10+10W
FLASHER UNIT

AP8124235  

Unit Price

14
BEEPER SUPPORT

AP8212165  

Unit Price

15
FUSE AND DIODE BOX

AP8212143  

Contact
16
FUSE 7, 5A
FUSE

AP8112244  

CM225607

Unit Price

17
BATTERY NEGATIVE LEADS

AP8112458  

Unit Price

18
SCREW
SCREW W/ FLANGE M6X35

AP8152282  

Unit Price

19
SELF-LOCKING NUT M6

AP8152299  

Unit Price

20
SCREW W/ FLANGE M6X25

AP8152280  

Unit Price

21
LIGHTS WIRING

AP8224017  

Contact
22
PLUGS SPRING

AP8121309  

Unit Price

23
SCREW 2, 2X12, 7

AP8150238  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Electrical system of your Aprilia RX Racing of RX. Let us know if you have any questions.
