Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Starter motor

TRANSMISSION COVER FOR APRILIA SR H2O NEW (IE+CARB.) 2006

Transmission final drive

Item numbers
Transmission cover Aprilia APRILIA-SCOOTER 50 SR 2006 SR H2O NEW (IE+Carb.)
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
TRASMISION COVER TYPHOON 50 (SIDECASE CO
TRANSMISSION COVER

8284535  

Unit Price

1
TRANSMISSION COVER PUREJET
TRANSMISSION COVER

8298225  

Unit Price

2
BUSH

286209  

Unit Price

3
BENDIX BUSH
BUSH Ø8XØ12X8

431860  

Unit Price

4
RUBBER BUFFER FOR TRANSMISION COVER
STAND END STOP

463872  

Unit Price

5
HEXAGONAL FLANGED HEAD SCREW(M6X35)
SCREW M6X35

414838  

Unit Price

6
BEARING

82521R  

Unit Price

7
PIN D.9, 5 H=15
REFERENCE PLUG (D9.5, H=15)

239388  

B015956

Unit Price

8
PLUG FOR CHECKING STARTER MOTOR
COVER

483859  

Unit Price

9
PLUG
COVER

829820  

Unit Price

10
STARTER AXLE WITH I.P.
STARTING SHAFT

831458  

Unit Price

11
START LEVER RETURN SPRING
STARTER LEVER RETURN SPRING

289495  

Unit Price

12
KICKSTART PINION
PINION STARTER

483537  

Unit Price

13
SPRING CLIP HOLDS KICKSTART GEAR
ELASTIC SPRING

830212  

Unit Price

14
COMPLETE KICKSTART LEVER FOR MOTOR
STARTER LEVER

286214  

Unit Price

15
KICKSTART LEVER RUBBER COVER
GUARD

286217  

Unit Price

16
VIS BRIDE M6X25
FLANGED HEXAGONAL SCREW M6X25

414837  

B016774

Unit Price

17
PLANE WASHER 16.3X23.8X0.6
WASHER 16, 3X23, 8

433987  

Unit Price

18
SPRING RING
CIRCLIP

006416  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

Genuine parts for Aprilia SR H2O NEW (IE+Carb.) 2006
