KAIFA FRONT FORK - HUBS, SLEEVES FOR APRILIA ATLANTIC 2002

LH Controls

Item numbers
Kaifa front fork - Hubs, sleeves Aprilia APRILIA-SCOOTER 500 ATLANTIC 2002 Atlantic
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
19
20
21
22
23
24
24
25
25
1
BUSH RING

AP8163424  

Unit Price

2
RETURN SPRING

AP8163422  

Contact
3
SCREW M10X30

AP8163285  

Unit Price

4
SEAL WASHER

AP8163414  

Contact
5
STOP RING D.37, 5X1, 2

AP8163433  

Contact
6
PLUG

AP8163432  

Unit Price

7
SPRING

AP8163430  

Contact
8
SHOCK ABSORBER

AP8163423  

Contact
9
HEX SOCKET SCREW M6X20

AP8223054  

Unit Price

10
STROKE LIMIT STOP

AP8163289  

Unit Price

11
SLEEVE CPL.

AP8163420  

Unit Price

12
BUSH
BUSHING

AP8163421  

Unit Price

13
DUST COVER

AP8163429  

Unit Price

14
STOP RING

AP8163428  

Contact
15
GASKET RING

AP8163427  

Unit Price

16
CUP

AP8163426  

Contact
17
UPPER SPRING GUIDE BUSH

AP8163425  

Contact
18
RH SLEEVE

AP8163415  

Contact
19
LH SLEEVE

AP8163416  

Contact
20
RH FRONT MUDGUARD SUPP.

AP8134819  

Contact
21
LH FRONT MUDGUARD SUPP.

AP8134800  

Contact
22
LH FRONT MUDGUARD SUPP.

AP8121532  

Contact
23
RH FRONT MUDGUARD SUPP.

AP8121564  

Contact
24
BUSH
BUSHING

AP8163419  

Unit Price

25
O-RING

AP8163431  

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Kaifa front fork - Hubs, sleeves of your Aprilia Atlantic of ATLANTIC. Let us know if you have any questions.
