MARZOCCHI FRONT FORK - HUBS, SLEEVES FOR APRILIA ATLANTIC 2004

Air box

Item numbers
Marzocchi front fork - Hubs, sleeves Aprilia APRILIA-SCOOTER 500 ATLANTIC 2004 Atlantic
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
10
10
11
12
13
13
14
14
15
15
16
16
17
17
18
19
20
21
22
23
1
BUSH RING

AP8123650  

Unit Price

2
RETURN SPRING

AP8163076  

Unit Price

3
SCREW M10X30

AP8123216  

Unit Price

4
SEAL WASHER

AP8123206  

Unit Price

5
STOP RING D37, 5X1, 2

AP8163150  

Unit Price

6
PLUG

AP8163151  

Contact
7
SPRING

AP8163152  

Unit Price

8
SHOCK ABSORBER

AP8163153  

Contact
9
SCREW

AP8123920  

Contact
10
STROKE LIMIT STOP

AP8123655  

Unit Price

11
RH HUB

AP8163154  

Contact
12
LH HUB

AP8163155  

Unit Price

13
DUST COVER + SPRING (MARZOCCHI)
DUST COVER FOR FORK TUBE

AP8123777  

599502

Unit Price

14
STOP RING

AP8123653  

Contact
15
GASKET RING (MARZOCCHI)
SEAL FOR INNER FORK TUBE

AP8103235  

599501

Unit Price

16
CUP (MARZOCCHI)
WASHER

AP8123360  

Contact
17
UPPER SPRING GUIDE BUSH

AP8123664  

Contact
18
RH SLEEVE

AP8163156  

Contact
19
LH SLEEVE

AP8163157  

Contact
20
RH FRONT MUDGUARD SUPP.

AP8134819  

Contact
21
LH FRONT MUDGUARD SUPP.

AP8134800  

Contact
22
LH FRONT MUDGUARD SUPP.

AP8121532  

Contact
23
RH FRONT MUDGUARD SUPP.

AP8121564  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Marzocchi front fork - Hubs, sleeves of your Aprilia Atlantic of ATLANTIC. Let us know if you have any questions.
