ELECTRICAL SYSTEM I FOR APRILIA RXV-SXV VDB-MERRIMAN 2008

Electrical system II

Item numbers

ELECTRONIC CONTROL UNIT

AP9100447

Contact

FIXING PLATE
CONTROL UNIT SUPPORT PLATE

851023

$8,91

Unit Price

BREATHER PIPE

AP8220598

$5,38

Unit Price

HEX SOCKET SCREW M4X20 TITAN

853591

Contact

HEX SOCKET SCREW M4X20

AP9100945

Contact

WASHER 4, 3X12X1 TITAN

853592

Contact

WASHER AP8150011
WASHER 4, 3X12X1

AP8150011

$3,65

Unit Price

LOW SELF-LOCKING NUT M4 TITAN

853593

Contact

LOW SELF-LOCKING NUT M4*
NUT M4

AP8150204

$2,95

Unit Price

VOLTAGE REGULATOR

AP9100424

Contact

SCREW W/ FLANGE M6X30 TITAN

853594

Contact

FLANGED HEXAGONAL HEAD SCREW M6X30
SCREW W/ FLANGE M6X30

AP8152281

$3,30

Unit Price

COIL

AP9100429

$138,48

Unit Price

SPARKPLUG CAP

AP9100423

$20,25

Unit Price

SCREW W/ FLANGE M6X16 TITAN

853595

Contact

SCREW W/ FLANGE
SCREW

AP8152278

598839

$0,09

Unit Price

RELAY
RELAY 12V-30A

AP8224462

$12,61

Unit Price

RELAY RUBBER
RUBBER SPACER *

AP8220283

$4,38

Unit Price

HORN

AP8127391

Contact

HEX SOCKET SCREW M8X12
HEX SOCKET SCREW

AP8152112

$3,65

Unit Price

CURVED SPRING WASHE 8, 4X15X0, 8
WASHER 8, 5X15X0, 8

AP8150376

$3,30

Unit Price

WASHER 8, 4X16X1, 6-ISO 7089 DA R40
WASHER 8, 4X16X1, 6

AP8150017

$3,65

Unit Price

FLASHER UNIT 12V 10+10W
FLASHER UNIT

AP8124235

$14,18

Unit Price

MAIN WIRING HARNESS

855053

Contact

MAIN WIRING HARNESS

855367

Contact

SPEED SENSOR

AP9100965

$113,74

Unit Price

SELF-TAPPING SCREW M4X12

AP8150460

$3,65

Unit Price

PROTECTION
PROTECTION BOX

858246

$15,22

Unit Price

INDICATORS ASSEMBLY

856665

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the Electrical system I of your Aprilia RXV-SXV Vdb-Merriman of RXV-SXV. Let us know if you have any questions.

Choose the exact model of your Aprilia RXV-SXV 550 to access the different categories of genuine spare parts
