Electrical system I

ELECTRICAL SYSTEM II FOR APRILIA SXV STREET LEGAL 2009

Exhaust unit

Item numbers

BATTERY 6AH YTX7A-BS
BATTERY

AP9100512

$137,03

Unit Price

CONTENITORE BATTERIA
BATTERY CASE CPL.

AP9101000

$20,60

Unit Price

RUBBER SPACER

AP8120001

$5,10

Unit Price

FRONT FAIRING GASKET
LH DUCT GASKET

AP8144538

890517

$15,22

Unit Price

RUBBER SPACER

AP9100725

Contact

RELAY BATTERY WIRING

AP9100371

$12,30

Unit Price

RUBBER PIPE 12, 8X8, 8 L=120

CM239401

Contact

GROUND-BATTERY LEAD

AP9100372

Contact

STARTER RELAY

AP9100487

$55,57

Unit Price

PLATE

AP9100325

$10,00

Unit Price

FUSE 30A
FUSE

AP8124273

CM225730

$6,53

Unit Price

STARTER MOTOR WIRING HARNESS

AP9100558

Contact

SCREW W/ FLANGE M5X12

AP8152272

$3,30

Unit Price

FUSE BLOCK SUPPORT

AP9100327

$5,38

Unit Price

FUSE

AP8176099

Contact

FUSE 7, 5A
FUSE

AP8112244

CM225607

$5,00

Unit Price

FUSE 15A
FUSES

AP8112176

CM225715

$7,23

Unit Price

PLATE

AP9100742

Contact

TEARING RIVET INOX

AP9100782

Contact

CAPACITOR 10000 UF
CONDENSER 10000 UF

AP9100739

$58,68

Unit Price

ENGINE-FRAME GROUND WIRING

AP9100783

Contact

TAILLIGHT WIRING HARN.

AP9100511

$19,99

Unit Price

SPRING

AP9100765

$5,38

Unit Price

SCREW
SCREW W/ FLANGE M6X12

AP8152277

$3,30

Unit Price

ALLEN SCREW M6X8 DA -8.8 UNI 5931
HEX SOCKET SCREW

AP8152123

$3,65

Unit Price

CURVED SPRING WASHER 6X12
HEXAG. HEAD SCREW

AP8150429

658830

$0,05

Unit Price

CURVED SPRING WASHER 5.5X10X0.5
CURVED SPRING WASHER 5, 3X10X0, 5

AP8150272

$3,65

Unit Price

ADHESIVE SPONGE 15X8
ADHESIVE SPONGE 15X8

AP8117004

890512

$2,48

Unit Price

MAIN WIRING HARNESS

859728

Contact

TERMINAL CAP

AP9100959

$5,38

Unit Price

GASKET

AP9100997

$5,38

Unit Price

RUBBER PIPE 12, 8X8, 8 L=95

CM239402

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
