Displacement

Model

Year

Finish line

Parts catalogue

Parts diagram

Foot rests

FRAME FOR APRILIA PEGASO STRADA - TRAIL IE 2005

Front body I

Item numbers

BLACK FRAME

AP8145026

Contact

GREY FRAME

AP8145076

Contact

BLACK FRAME

AP8146917

Contact

FRONT ENGINE SUPPORT

AP8146915

Contact

ENGINE SUPPORT, INF.

AP8146921

Contact

RH CYLINDER-FRAME PLATE

AP8146922

Contact

LH CYLINDER-FRAME PLATE

AP8146923

Contact

SUPPORT CLAMP SAS

AP8146920

Contact

VOLTAGE REGULATOR SUPPORT

AP8146919

Contact

OIL FILTER

AP8104911

Contact

WASHER D8X16X1, 5

AP8121862

$3,65

Unit Price

FLANGED HEXAGONAL HEAD M8X20
SCREW W/ FLANGE M8X20

AP8152286

$3,30

Unit Price

OIL FILLER CAP W/ DIPSTICK

AP8102393

$8,91

Unit Price

O-RING 4087

AP8120280

$3,65

Unit Price

SPACER
SPACER *

AP8101108

$3,65

Unit Price

SPACER
SPACER *

AP8121092

$3,65

Unit Price

CHAIN TENSIONER ROLLER

AP8101704

Contact

WASHER 8.5X24X2 DA UNI 6593 R40
WASHER

AP8150018

Contact

SCREW W/ FLANGE M8X50

AP8152292

$3,65

Unit Price

NUT M8 -UNI 7474-INOX A2-70
LOW NUT M8

AP8150431

$3,30

Unit Price

HOSE CLIP 20X8

AP8102786

$5,10

Unit Price

RUBBER SPACER

AP8144714

Contact

SPACER

AP8161051

$1,59

Unit Price

WASHER 6, 6X18X1, 6
WASHER 6, 6X18X1, 6*

AP8150015

$3,30

Unit Price

FLANGED HEXAGONAL HEAD M6X40
SCREW W/ FLANGE

AP8152283

$2,95

Unit Price

SCREW W/ FLANGE M10X110

AP8152315

Contact

SCREW W/ FLANGE M10 X 25
SCREW W/ FLANGE

AP8152473

$7,96

Unit Price

SELF-LOCKING NUT M10
SELF-LOCKING NUT

AP8152301

$3,30

Unit Price

SCREW
SCREW W/ FLANGE M6X12

AP8152277

$3,30

Unit Price

RH FRAME PROTECTION, CARB.

852447

Contact

RH FRONT FOOTREST GUARD, GREY

AP8146962

Contact

RH FRONT FOOTREST GUARD, BLACK

AP8184426

Contact

LH FRAME PROTECTION, CARB.

852448

Contact

LH FRONT FOOTREST GUARD, GREY

AP8146963

Contact

LH FRONT FOOTREST GUARD, BLACK

AP8184427

Contact

INSERT

AP8144730

Contact

INSERT

AP8144731

Contact

INSERT

AP8144747

Contact

INSERT

AP8144748

Contact

PUSH ON FASTENERS FOR 5MM SHAFT
WASHER FOR SHAFTS D5

AP8150450

$3,65

Unit Price

MUSHROOM RUBBER

AP8220488

$4,62

Unit Price

HEXAGON COCKET SCREWS M5X20
SCREW W/ FLANGE

AP8152338

$3,65

Unit Price

WASHER 10, 5X21X2*

AP8150020

$3,30

Unit Price

SCREW W/ FLANGE M10X85

AP8152482

$4,04

Unit Price

FLANGED HEXAGONAL HEAD M10X55 DA-8.8
SCREW W/ FLANGE M10X55

AP8152410

$3,65

Unit Price

SCREW FLANGED M10X70 DA-8.8
SCREW W/ FLANGE

AP8152481

$3,36

Unit Price

WASHER 15X5, 5X1, 2

AP8150382

$3,65

Unit Price

T BUSH

AP8121811

$3,38

Unit Price

CURVED SPRING WASHER 5.5X10X0.5
CURVED SPRING WASHER 5, 3X10X0, 5

AP8150272

$3,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!

All the genuine spare parts for the Aprilia 2005
