SWING ARM FOR APRILIA PEGASO STRADA - TRAIL IE 2006

Air box

Item numbers
Swing arm Aprilia APRILIA-MOTORCYCLES 650 PEGASO 2006 Pegaso Strada - Trail IE
1
1
2
3
4
5
6
6
7
8
9
10
10
11
12
13
14
15
15
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
29
29
1
SWING ARM, SAND.GR.

AP8145078  

Contact
1
SWING ARM, SAND.GR.

AP8146928  

Contact
2
RH CHAIN TENSIONER

AP8144702  

Contact
3
LH CHAIN TENSIONER

AP8144703  

Unit Price

4
CHAIN GUIDE PLATE

AP8144687  

Contact
5
CUP FOR SHOE

AP8234020  

Unit Price

6
SCREW M4, 8X13
SCREW

AP8150246  

Unit Price

7
CHAIN TENS.ADJUSTER SCREW

AP8152305  

Unit Price

8
LOW NUT

AP8152262  

Contact
9
REAR SWING ARM PIN
REAR SWING ARM PIN D16

AP8161038  

Unit Price

10
NEEDLE BEARING 25X32X24

AP8110070  

Contact
11
REAR SW.ARM PIV.BUSH

AP8161041  

Contact
12
ADJUSTMENT BUSH

AP8161028  

Unit Price

13
RING NUT M17X1

AP8150299  

Contact
14
WASHER 17X30X3
WASHER 17X30X3*

AP8152063  

Unit Price

15
WASHER

AP8120872  

Contact
16
CRINKLE WASHER

AP8150445  

Contact
17
REAR WHEEL SPINDLE

AP8161040  

Contact
18
WHEEL PIN WASHER

AP8125687  

Unit Price

19
REAR WHEEL SPINDLE NUT

AP8125763  

Unit Price

20
BLACK PLUG

AP8105139  

Contact
21
HEXAGONAL RIVET M5
THREADED RIVET

AP8201755  

Unit Price

22
SHOCK ABSORBER COVER

AP8179017  

Unit Price

23
/
T BUSH *

AP8121075  

Unit Price

24
CLIP M5

AP8102375  

Unit Price

25
UPPER CHAIN GUARD

AP8178810  

Contact
26
HEXAGON COCKET SCREWS M5X12
SCREW W/ FLANGE M5X12

AP8152302  

Contact
27
REAR STAND BUSH

AP8121890  

Unit Price

28
COUNTERSUNK SCREW M 6 X 40-UNI 5933 10.9
SCREW M6X40

AP8150468  

Unit Price

29
CHAIN/TYRES DECAL

AP8166599  

Contact
29
CHAIN DECAL

AP8166680  

Contact
Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
