CENTRAL BODY I FOR APRILIA NA MANA 2009

Front body - Front mudguard

Item numbers

SCREW
PHILLIPS SCREW, SWP M5X20

AP8152329

$3,30

Unit Price

HELMET COMPARTM.COVER PROTECT.

85193100XD1

Contact

COVER
HELMET COMPARTM.COVER PROTECT.

86043800BM

$363,96

Unit Price

CASE-HELMET COVER
HELMET COMPARTM.COVER PROTECT.

86043800XN2

$363,96

Unit Price

COVER
HELMET COMPARTM.COVER PROTECT.

86043800XN5

$363,96

Unit Price

COVER
HELMET COMPARTM.COVER PROTECT.

86043800XR7

$363,96

Unit Price

CASE-HELMET COVER
CASE-HELMET COVER

85193100XED

86043800XED

$363,96

Unit Price

HELMET COMPARTM.COVER PROTECT.
CASE-HELMET COVER

85193100XN2

86043800XN2

$363,96

Unit Price

CASE-HELMET COVER, RED
CASE-HELMET COVER, RED

85193100XR2

86043800XR2

$363,96

Unit Price

BRACKET
HELMET COMPARTMENT COVER

860439

$21,31

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

GASKET

851941

$10,56

Unit Price

HELMET HUOSING BUSH
BUSHING

854797

$1,25

Unit Price

HELMET HUOSING PIN
PIN

854796

$1,07

Unit Price

STEERING LOCK COVER

851929

$4,82

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

HEXAGON COCKET SCREWS M6X30 Z.N.
HEX SOCKET SCREW M6X30

AP8152128

$3,30

Unit Price

WASHER
WASHER 6, 4X15X1

AP8152181

$2,66

Unit Price

BRACKET INJECTION POWER UNIT
CONTROL UNIT SUPPORT PLATE

852295

$5,73

Unit Price

SCREW CLIP D5, 5
SCREW CLIP D5, 5*

AP8201764

$3,65

Unit Price

SCREW 5, 5X15, 9
SCREW 5, 5X15, 9*

AP8150426

$3,65

Unit Price

HELMET HUOSING DAMPER
HELMET COMPARTMENT DAMPER

851922

$21,66

Unit Price

PIN
PIN M8

854578

$1,35

Unit Price

T BUSH
T BUSH *

AP8120508

$3,65

Unit Price

SELF-LOCKING NUT M8*
SELF-LOCKING NUT M8

AP8152300

$3,30

Unit Price

SCREW
SCREW W/ FLANGE M6X20

AP8152279

$3,30

Unit Price

WASHER
WASHER 6, 4X15X1

AP8152181

$2,66

Unit Price

/
T BUSH *

AP8121075

$3,65

Unit Price

FORK

858151

$9,36

Unit Price

FORK PIN
FORK GUIDE PIN

858152

$2,08

Unit Price

CLAMP
BRACKET

858385

$3,58

Unit Price

SLIDING BLOCK

858386

$16,66

Unit Price

SCREWS FOR PLASTIC INOX-SWP 3, 9X10 T
SELF-TAPPING SCREW

AP8150444

$3,65

Unit Price

SCREW
SCREW W/ FLANGE

598839

$0,09

Unit Price

T BUSH

AP8121728

$6,08

Unit Price

SELF-LOCKING NUT M6

AP8152299

$3,30

Unit Price

RH HELMET HUOSING
RH HELMET COMPARTMENT

890380

$19,49

Unit Price

LH HELMET HUOSING
LH HELMET COMPARTMENT

890381

$21,79

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
