1
Engine displacement
1000
2
Model
TUONO
3
Year
2004
4
Trim
RSV 1000 Tuono
5
Parts Catalog
Racing 2003 fuel pump
6
Parts Diagram
Parts Catalog
Front body - Front fairing
by
Crankcases II
Racing 2003 fuel pump
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
22
23
24
25
26
1
Fuel pump flange
AP8134750
$51,49 Unit Price incl. VAT
2
Self-tap screw 2,9x9,5
AP8104455
Not Available
3
White hose clip D.13,5x6
AP8102765
$3,59 Unit Price incl. VAT
4
screw
AP8121536
$3,65 Unit Price incl. VAT
5
Bored screw
AP8106443
$23,22 Unit Price incl. VAT
6
Gasket ring
AP8176032
Not Available
7
Fuel pipe
AP8144226
$10,00 Unit Price incl. VAT
8
Fuel filter
AP8102971
$74,03 Unit Price incl. VAT
9
Fuel pum kit
AP8176078
Not Available
10
Gasket 18x12,2x1,5
AP8106444
Not Available
11
Hose clamp
AP8104458
Not Available
12
Screw w/ flange M6x16
AP8152278
$1,77 Unit Price incl. VAT
13
Level sensor
AP8127540
$56,87 Unit Price incl. VAT
14
Fuel pipe
AP8144476
$7,23 Unit Price incl. VAT
15
White hose clip d.13x6
AP8102764
$1,86 Unit Price incl. VAT
16
Washer 6,4x12*
AP8152184
$3,65 Unit Price incl. VAT
17
2-way union
AP8102626
Not Available
18
Screw w/ flange M6x12
AP8152277
$0,25 Unit Price incl. VAT
19
Joint
AP8102873
$10,00 Unit Price incl. VAT
20
Fuel pump wiring
AP8127321
Not Available
21
Screw w/ flange M5x15
AP8152273
$0,16 Unit Price incl. VAT
22
Fuel pipe 6x13
AP8144069
Not Available
23
Hose clamp 12,5x8
AP8102239
$0,84 Unit Price incl. VAT
24
Fuel pipe
AP8120992
Not Available
25
Joint
AP8102829
Not Available
26
Gasket ring
AP8144475
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
