BODY FOR APRILIA SX LIMITED EDITION 2015

Frame

Item numbers

FRONT MUDGUARD

2B000015000W0B

$24,58

Unit Price

FRONT MUDGUARD

2B000015000W0N

$23,48

Unit Price

HEXAGONAL SOCKET SCREW M6X16
SCREW W/ FLANGE M6X16

AP8152246

$3,30

Unit Price

SCREW M6X12
SCREW 6MX100X12

00012061200

$3,65

Unit Price

R.H. BODY SIDE
RH FRONT SIDE PANEL

2B000013000W0N

$15,16

Unit Price

R.H. BODY SIDE
LH FRONT SIDE PANEL

2B000014000W0N

$15,16

Unit Price

COUVRE-STR.SELLE D, NOIR
RH SADDLE SUP COVER

86108200W0N

$3,83

Unit Price

LH SADDLE SUP COV., BLACK
LH SADDLE SUP COVER

86108300W0N

$4,05

Unit Price

SPRING PLATE M6

254485

$3,30

Unit Price

HEXAGONAL SOCKET SCREW M6X16
SCREW W/ FLANGE M6X16

AP8152246

$3,30

Unit Price

SCREWS FOR PLASTIC INOX -SWP 3, 9X7, 5
SELF-TAPPING SCREW *

AP8150420

$3,65

Unit Price

NUMBER PLATE HOLDER

894118

$5,14

Unit Price

REFLECTOR

00K05110651

Contact

REAR MUDGUARD

00H00705121

Contact

GEAR MUDFLAT
REAR FAIRING

2B000012000W0B

$13,63

Unit Price

GEAR MUDFLAT
REAR FAIRING

2B000012000W0N

$12,81

Unit Price

REFLECTOR

00H01802081

$7,94

Unit Price

MACHINED FLAT WASHER D6 DIN-12
WASHER D6 DIN125 AZNB

00402060001

$3,65

Unit Price

WASHER 5, 5X15X1, 2 DA UNI 6593 R50
WASHER 5, 5X15X1, 6*

AP8150013

$3,65

Unit Price

LOW SELF-LOCKING NUT M4*
NUT M4

AP8150204

$2,95

Unit Price

GUARD

00H02201591

Contact

RUBBER SPACER

00D01500021

Contact

WASHER
WASHER

00000031050

847226

$2,25

Unit Price

SELF-TAPPING SCREW
SELF-TAP SCREW 3, 9X14

AP8150413

$3,30

Unit Price

ALLEN SCREW M5X15
SCREW

00002052051

$3,65

Unit Price

CLIP M5

AP8102375

$3,30

Unit Price

FLANGE D8 D8
BRIDA PASACABLES D8 ISC NG

00H01501811

864454

$3,65

Unit Price

SELF-LOCKING NUT M6

AP8152299

$3,30

Unit Price

HOSE CLAMP D.8
BLACK HOSE D8

AP8101890

$3,65

Unit Price

HEX SOCKET SCREW M6X25
HEX SOCKET SCREW M6X25

00002062511

AP8150165

$3,65

Unit Price

SELF-LOCKING NUT M6
NUT M6100

00000023060

$2,95

Unit Price

WASHER 4, 3X9X0, 8 DA ISO 7089 R40
WASHER 4, 3X9X0, 8

AP8150158

$3,65

Unit Price

PUSH ON FASTENERS FOR 5MM SHAFT
WASHER FOR SHAFTS D5

AP8150450

$3,65

Unit Price

WASHER 6, 4X12, 5
WASHER 6, 4X12, 5*

AP8150178

$3,30

Unit Price

LATERAL PROTECTION
RH REAR PANEL

2B000010000W0B

Contact

LATERAL PROTECTION
RH REAR PANEL

2B000010000W0N

$11,93

Unit Price

LATERAL PROTECTION
LH REAR PANEL

2B000011000W0B

Contact

LATERAL PROTECTION
LH REAR PANEL

2B000011000W0N

$11,93

Unit Price

WASHER
WASHER D6

00D01200171

$3,65

Unit Price

BUSH
RING NUT

862449

$0,43

Unit Price

TENSION
TIE ROD

89411900XN4

$6,02

Unit Price

SCREW W/ FLANGE M5X16

AP8152298

$3,30

Unit Price

HEXAGON COCKET SCREWS M5X9
SCREW W/ FLANGE M5X9

AP8152339

$3,65

Unit Price

BUSHING
BUSH

AP8121032

$3,30

Unit Price

RUBBER
RUBBER SPACER

AP8120405

$5,38

Unit Price

WASHER

00H03800722

Contact

SCREW
PHILLIPS SCREW, SWP M5X20

AP8152329

$3,30

Unit Price

COVER
WIRING COVER

894122

$4,00

Unit Price

BUSHING
BUSH

AP8121032

$3,30

Unit Price

SPACER

840509

$0,48

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
