SWING ARM FOR APRILIA SX LIMITED EDITION 2015

Water cooler

Item numbers

SWING ARM

B045013

Contact

REAR WHEEL AXLE SUB-ASSEMBLY G
REAR WHEEL AXLE SUB-ASSEMBLY G

00H01304202

00H013042025

$27,97

Unit Price

WASHER 12, 2X22X2

AP8152018

$3,65

Unit Price

SWING ARM BUSHING
BUSH

00002503230

$3,65

Unit Price

SPACER

00H00301401

Contact

WASHER

00D01300192

Contact

SELF-LOCKING NUT 12M150
NUT

00262120032

$3,65

Unit Price

CHAIN GUIDE PLATE

00H01803331

Contact

SCREW, SELF TAPPING 4.8MM13
SCREW 4, 8X13

00011141300

$3,65

Unit Price

WASHER 5, 3X10X1

AP8150177

$5,38

Unit Price

CHAIN COVER

00H01508181

Contact

SPRING PLATE M6

254485

$3,30

Unit Price

HEXAGON COCKET SCREWS M6X12 Z.N.
HEX SOCKET SCREW

AP8150340

$3,65

Unit Price

HEXAGON COCKET SCREWS M6X15 Z.N.
HEX SOCKET SCREW

AP8152108

$3,30

Unit Price

WASHER
WASHER 6, 4X15X1

AP8152181

$2,66

Unit Price

SCREW
SCREW M4, 8X13

00011041300

AP8150246

$3,65

Unit Price

WIRING CLIP
HOSE CLAMP

AP8102151

890721

$1,15

Unit Price

CHAIN GUIDE

86133R

$24,59

Unit Price

SPRING CUP
BELLEVILLE SPRING

AP8121697

$3,65

Unit Price

SCREW
SCREW W/ FLANGE M6X12

AP8152277

$3,30

Unit Price

SCREW 12X45

00H00300912

Contact

SELF-LOCKING NUT 12M175
NUT 12MX175

00023112000

$3,65

Unit Price

SHOCK ABSORBER
REAR SHOCK ABSORBER

8670020001

$231,44

Unit Price

SCREW

00H00303892

Contact

SCREW
SCREW W/ FLANGE M6X12

AP8152277

$3,30

Unit Price

CHAIN GUIDE PLATE

00H01305171

Contact

MACHINED FLAT WASHER D6 DIN-12
WASHER D6 DIN125 AZNB

00402060001

$3,65

Unit Price

SELF-LOCKING NUT M6
NUT M6100

00000023060

$2,95

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Aprilia. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Aprilia, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
