1
Engine displacement
50
2
Model
RS
3
Year
2003
4
Trim
RS 50
5
Parts Catalog
Front body I
6
Parts Diagram
Parts Catalog
Swing arm - Shock absorber
by
Front body II
Front body I
1
2
3
3
4
4
5
6
7
7
8
9
10
10
11
12
13
1
Front fairing, d.black
AP8258191
$434,97 Unit Price incl. VAT
1
Front fairing, fumi blue
AP8248791
Not Available
1
Front fairing, a.black
AP8239454
Not Available
1
Front fairing, black
AP8258817
Not Available
1
Front fairing, a.black
AP8268456
Not Available
1
Front fairing, black
AP8258775
Not Available
1
Front fairing, grey
AP8258567
Not Available
1
Front fairing, a.black
AP8268379
Not Available
1
Front fairing, black
AP8268158
Not Available
1
Front fairing, blue
AP8258792
Not Available
1
Front fairing, n.grey
AP8249810
Not Available
1
Front fairing, white
AP8268266
Not Available
1
Front fairing, black
AP8249591
Not Available
1
Front fairing, d.black
AP8258422
Not Available
2
RH rearview mirror
AP8102632
$28,35 Unit Price incl. VAT
3
Mirror joint cup
AP8102341
$3,65 Unit Price incl. VAT
4
Mirror insertion kit
AP8102909
$6,35 Unit Price incl. VAT
5
LH rearview mirror
AP8102633
$28,35 Unit Price incl. VAT
6
Windshield
AP8139724
Not Available
6
Windshield
AP8138916
Not Available
6
Windshield
AP8148663
Not Available
6
Windshield
AP8249094
Not Available
7
Screw w/ flange M6x16
AP8152246
$0,27 Unit Price incl. VAT
8
Fixing pin
AP8144109
$5,38 Unit Price incl. VAT
9
Washer for shafts D5
AP8150450
$0,25 Unit Price incl. VAT
10
Screw w/ flange M5x12
AP8152302
Not Available
11
Clip M5
AP8102375
$0,69 Unit Price incl. VAT
12
O-ring 2018
AP8120965
$3,65 Unit Price incl. VAT
13
Front fairing glass decal
AP8157105
$24,90 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
