1
Engine displacement
50
2
Model
SR
3
Year
2003
4
Trim
SR H2O (Ditech E2)
5
Parts Catalog
Front lights
6
Parts Diagram
Parts Catalog
Front wheel
by
Starter motor
Front lights
1
2
2
3
4
5
6
6
6
6
7
8
9
10
11
12
13
14
15
16
17
17
18
1
Front headlight guard
AP8212841
$6,30 Unit Price incl. VAT
2
screw
AP8225359
Not Available
3
Headlight -35+35W-
AP8212903
Not Available
3
Headlight
AP8212771
Not Available
4
LH shield
AP8224211
$4,32 Unit Price incl. VAT
5
RH shield
AP8224214
Not Available
6
Screw 4,2x20*
AP8150270
$3,65 Unit Price incl. VAT
7
RH Turn indicator f.lens
AP8224213
$5,67 Unit Price incl. VAT
8
Headlight wiring w/harness
AP8224149
Not Available
8
Headlight wiring w/harness
AP8224148
Not Available
9
plate
AP8224062
Not Available
10
Self-tap screw M2,9x6,5
AP8224063
$3,65 Unit Price incl. VAT
11
RH turn light parabola
AP8224215
Not Available
12
LH turn light parabola
AP8224212
Not Available
13
LH front turn indicator lens
AP8224210
Not Available
14
RH front turn indicator
AP8124516
Not Available
15
LH front turn indicator
AP8124517
Not Available
16
Lamp S3 15w 12v
AP8224392
Not Available
17
Lamp R10W 12v
AP8224390
Not Available
18
Turn indicator wiring kit-CH-
AP8224514
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
