1
Engine displacement
50
2
Model
SR
3
Year
2004
4
Trim
SR H2O (Ditech E2)
5
Parts Catalog
Front fork I
6
Parts Diagram
Parts Catalog
Front body IV
by
Central stand - Connecting rod
Front fork I
1
2
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
15
1
Stem base
AP8223004
$112,55 Unit Price incl. VAT
2
Plug
AP8203777
$5,38 Unit Price incl. VAT
2
Plug
AP8223038
$5,38 Unit Price incl. VAT
2
Plug
AP8203561
$5,38 Unit Price incl. VAT
3
Ring
AP8223039
$3,65 Unit Price incl. VAT
3
Ring
AP8203778
$3,65 Unit Price incl. VAT
3
O-ring
AP8203652
$3,65 Unit Price incl. VAT
4
Stop ring
AP8203752
$3,65 Unit Price incl. VAT
4
Stop ring
AP8203702
Not Available
5
Cover
AP8203753
Not Available
5
Cover
AP8203779
Not Available
5
Cover
AP8223041
$5,38 Unit Price incl. VAT
6
O-ring
AP8223042
$3,65 Unit Price incl. VAT
6
O-ring
AP8203780
$3,65 Unit Price incl. VAT
6
O-ring
AP8203754
$8,01 Unit Price incl. VAT
7
pipe
AP8203755
$5,38 Unit Price incl. VAT
8
Spring
AP8223049
$5,38 Unit Price incl. VAT
8
Spring
AP8203756
Not Available
8
Spring
AP8203781
Not Available
9
Shock absorber, LH
AP8203757
Not Available
9
Shock absorber, LH
AP8203782
$70,25 Unit Price incl. VAT
10
Fork pump ring
AP8203783
Not Available
10
Fork pump ring
AP8223046
$5,38 Unit Price incl. VAT
10
Fork pump ring
AP8203758
$5,38 Unit Price incl. VAT
11
Shock absorber, RH
AP8203759
$72,09 Unit Price incl. VAT
11
Shock absorber, RH
AP8203784
$70,25 Unit Price incl. VAT
12
screw M10x35
AP8203762
$3,65 Unit Price incl. VAT
12
screw
AP8203797
Not Available
13
Return spring
AP8123708
$8,91 Unit Price incl. VAT
13
Return spring
AP8223050
$5,38 Unit Price incl. VAT
13
Return spring
AP8203786
$5,38 Unit Price incl. VAT
14
Front fork
AP8203986
Not Available
15
Plunger, complete
AP8223045
$7,23 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
