Engine displacement
850
2
Model
NA-MANA
3
Year
2016
4
Trim
NA Mana GT
5
Parts Catalog
Lock hardware kit
6
Parts Diagram
Parts Catalog
Rear cylinder timing system
by
Drive shaft
Lock hardware kit
16
15
15
14
14
13
13
12
12
11
10
9
8
7
6
5
5
4
3
2
1
17
18
1
Lock kit
894544
Not Available
2
Lock cable
852399
$6,25 Unit Price incl. VAT
3
Lock cable
852400
$7,90 Unit Price incl. VAT
4
"Aprilia" key with transpo.
AP8104920
Not Available
5
Saddle lock
AP8102945
$13,53 Unit Price incl. VAT
6
Lever
577861
$1,35 Unit Price incl. VAT
7
Pin
AP8161179
Not Available
8
Solenoid valve
AP8161172
Not Available
9
Spacer *
AP8121773
$3,38 Unit Price incl. VAT
10
Shear rivet M8x40
AP8150351
$7,62 Unit Price incl. VAT
11
Lock cable
851944
$3,00 Unit Price incl. VAT
12
Bush
AP8121032
$0,59 Unit Price incl. VAT
13
Screw w/ flange M6x16
AP8152246
$0,27 Unit Price incl. VAT
14
Phillips screw, SWP M5x20
AP8152329
$0,69 Unit Price incl. VAT
15
Screw 5,5x15,9*
AP8150426
$3,65 Unit Price incl. VAT
16
Key switch
894546
Not Available
17
Lever
577129
$1,43 Unit Price incl. VAT
18
Saddle lock plate
577130
$5,35 Unit Price incl. VAT

Find the detailed Lock hardware kit APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
