1
Engine displacement
250
2
Model
ATLANTIC
3
Year
2006
4
Trim
Atlantic
5
Parts Catalog
Ignition unit I
6
Parts Diagram
Parts Catalog
Variator cover
by
Ignition unit II
Ignition unit I
1
2
3
4
5
6
6
7
8
9
10
11
11
12
13
14
14
15
16
17
18
19
20
21
22
1
Flywheel cover cpl.
AP8176248
Not Available
2
Locating dowel
AP8551015
Not Available
3
Gasket ring
AP8590055
Not Available
4
Water pump shaft assy.
AP8176277
Not Available
5
Pump impeller drive key
AP8580104
Not Available
6
Bearing 28x8x9
AP8577012
Not Available
7
Cdi magneto assy
AP8580250
Not Available
8
Water pump cover
AP8176287
Not Available
9
Fan
AP8276091
Not Available
10
By-pass pipe
AP8176288
Not Available
11
Screw
AP8551060
Not Available
12
Pump-cylinder hose
AP8575034
Not Available
13
O-ring
AP8580084
Not Available
14
Hose clamp
AP8580217
Not Available
15
Transmission key
AP8550039
Not Available
16
Nut cpl.
AP8550134
Not Available
17
screw
AP8580161
Not Available
18
Washer
AP8550477
Not Available
19
Cover
AP8580116
Not Available
20
Special screw
AP8580163
Not Available
21
Washer
AP8580162
Not Available
22
Hose clamp
AP8144579
$3,65 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
