1
Engine displacement
125
2
Model
MX
3
Year
2004
4
Trim
MX SuperMotard
5
Parts Catalog
Rear wheel
6
Parts Diagram
Parts Catalog
Front wheel
by
Rear master cylinder
Rear wheel
1
2
3
4
5
6
7
8
9
10
10
11
12
12
13
14
15
16
16
17
18
19
20
20
21
22
1
Tyre
0000000
Not Available
2
Tyre
0000000
Not Available
3
Rear wheel flap 18"
AP8109281
$13,53 Unit Price incl. VAT
4
Rear wheel
AP8128057
Not Available
5
RH front spoke D.3,5
AP8128054
Not Available
6
Spoke D.3,5
AP8128055
$1,15 Unit Price incl. VAT
7
Nipples D3,5
AP8108672
$6,30 Unit Price incl. VAT
8
Rear clutch grey
AP8125707
Not Available
9
Spacer
AP8125477
Not Available
10
Hub bearing D17x40x12
AP8110045
$9,18 Unit Price incl. VAT
11
Circlip d40
AP8125784
$0,66 Unit Price incl. VAT
12
Oil seal 30x40x7
AP8125462
$5,38 Unit Price incl. VAT
13
Rear wheel spindle
AP8125579
$17,06 Unit Price incl. VAT
14
Low self-locking nut M16x1,5*
AP8150433
$3,65 Unit Price incl. VAT
15
Washer 17x30x3*
AP8152063
$3,65 Unit Price incl. VAT
16
Rear wheel spacer
AP8125580
Not Available
17
Chain ring
AP8107128
Not Available
18
Low nut M8
AP8150431
$0,34 Unit Price incl. VAT
19
Washer 8,5x15x0,8
AP8150376
$0,08 Unit Price incl. VAT
20
Screw M8x26
AP8152196
$3,65 Unit Price incl. VAT
21
Chain cpl conn.link
AP8107104
$74,32 Unit Price incl. VAT
22
Rear wheel
AP8128098
Not Available
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
