1
Engine displacement
50
2
Model
RX
3
Year
2000
4
Trim
RX
5
Parts Catalog
Air box
6
Parts Diagram
Parts Catalog
Water cooler
by
Oil tank
Air box
10
9
9
9
8
7
6
5
4
3
2
1
1
Filter housing base
AP8230645
Not Available
2
Filter housing cover
AP8230644
Not Available
3
Filter with guard
AP8201429
Not Available
4
Gasket D4
AP8120593
Not Available
5
Hose collar
AP8201799
$3,65 Unit Price incl. VAT
6
Intake hose
AP8220642
Not Available
6
Intake hose
AP8220409
Not Available
7
Washer
AP8120592
$0,16 Unit Price incl. VAT
8
Screw w/ flange M6x30
AP8152281
$1,70 Unit Price incl. VAT
9
Screw w/ flange M6x25
AP8152280
$0,25 Unit Price incl. VAT
10
Washer 6,4x15x1
AP8152181
$0,07 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
