Parts Catalog
Crankshaft assy
6
Parts Diagram
Parts Catalog
Drive shaft
by
Lock hardware kit
Crankshaft assy
1
2
3
3
4
5
6
7
8
9
9
9
9
10
10
10
10
11
12
13
13
14
14
14
15
15
15
16
1
Frame coupling rod
AP8146381
Not Available
2
Engine connecting element
AP8146380
Not Available
3
Connecting rod pin
AP8161037
Not Available
4
Pin
AP8121580
Not Available
5
T bush
AP8161036
Not Available
6
Rod bush
AP8121590
Not Available
7
Spacer
AP8121460
Not Available
8
Spacer
AP8121459
Not Available
9
Douille glissement;
AP8121311
$4,36 Unit Price incl. VAT
10
Dust cover
AP8121551
Not Available
11
Ring nut
AP8121611
Not Available
12
Bush
AP8121612
$12,36 Unit Price incl. VAT
13
Pad
AP8144334
$13,53 Unit Price incl. VAT
14
Rondelle
AP8150208
$3,65 Unit Price incl. VAT
15
Low self-locking nut M14x1,5*
AP8152030
Not Available
16
Connecting rod cpl.
AP8146941
Not Available

Find the detailed Crankshaft assy APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.
