1
Engine displacement
125
2
Model
MX
3
Year
2005
4
Trim
MX SuperMotard
5
Parts Catalog
Air box
6
Parts Diagram
Parts Catalog
Water cooler
by
Engine
Air box
23
22
22
21
20
19
18
17
16
16
15
15
14
14
13
13
12
11
10
9
9
9
8
8
7
6
6
5
4
3
2
1
1
Filter housing base
AP8268155
Not Available
2
Intake hose
AP8120997
$13,53 Unit Price incl. VAT
3
Battery plate
AP8131680
$1,81 Unit Price incl. VAT
4
Carburettor-air box hose
AP8120654
Not Available
5
Filter housing cover
AP8130574
Not Available
6
Filter support guard-couple
AP8130596
Not Available
7
Air filter
AP8101851
Not Available
8
Screw
AP8150060
Not Available
9
Washer 6,6x18*
AP8150179
$0,08 Unit Price incl. VAT
10
Nut M6
AP8150026
$0,16 Unit Price incl. VAT
11
Hose clamp D=60-80
AP8120246
$3,65 Unit Price incl. VAT
12
Yel.zinc square nut M6x12x12
AP8150386
Not Available
13
Curved spring washer *
AP8150182
$0,08 Unit Price incl. VAT
14
Screw w/ flange M6x16
AP8152278
$1,77 Unit Price incl. VAT
15
Screw 3x15*
AP8152114
Not Available
16
Washer 3,2x7x0,5*
AP8150233
$0,05 Unit Price incl. VAT
17
Low self-locking nut
AP8150430
$0,16 Unit Price incl. VAT
18
Adhesive sponge 6x30
AP8117041
$5,38 Unit Price incl. VAT
19
Intake pipe sas
AP8144660
Not Available
20
Air pipe sas
AP8144661
Not Available
21
Valve SAS
AP8104745
Not Available
22
Hose clip D.15,5x6,6
AP8101586
$5,73 Unit Price incl. VAT
23
Screw w/ flange M6x12
AP8152277
$0,25 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
