1
Engine displacement
125
2
Model
MX
3
Year
2005
4
Trim
MX SuperMotard
5
Parts Catalog
Rear brake caliper
6
Parts Diagram
Parts Catalog
Rear master cylinder
by
Lights
Rear brake caliper
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
1
Rear brake disc
AP8113462
$99,15 Unit Price incl. VAT
2
Brake hanger plate
AP8134481
Not Available
3
Rear brake caliper, grey
AP8133708
Not Available
4
Pads (pair)
AP8113375
$49,62 Unit Price incl. VAT
5
Air bleed valve
AP8113006
$24,59 Unit Price incl. VAT
6
Bleed valve cap
AP8113005
$5,38 Unit Price incl. VAT
7
Rear brake spring
AP8133728
$5,09 Unit Price incl. VAT
8
Oil pipe screw
AP8113003
$3,65 Unit Price incl. VAT
9
Washer 10x14x1,6*
AP8113004
$0,34 Unit Price incl. VAT
10
Rear brake hose
AP8113555
Not Available
11
Screw
AP8152259
$0,22 Unit Price incl. VAT
12
Washer
AP8150009
$3,65 Unit Price incl. VAT
13
Screw w/ flange M8x20
AP8152286
$0,25 Unit Price incl. VAT
14
Brake caliper rev. kit
AP8133727
$9,09 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
