Engine displacement
125
2
Model
ATLANTIC
3
Year
2007
4
Trim
Atlantic
5
Parts Catalog
Crankshaft assy
6
Parts Diagram
Parts Catalog
Frame
by
Central stand
Crankshaft assy
1
2
3
4
4
4
4
5
5
5
5
5
5
6
7
7
7
7
8
8
9
9
10
11
12
13
14
15
16
1
Biellette fixation châssis;
AP8146548
$100,52 Unit Price incl. VAT
2
Engine connecting element
AP8146898
Not Available
3
Douille biellette
AP8121561
$36,22 Unit Price incl. VAT
4
Ecrou autofr. bas
AP8150432
$3,65 Unit Price incl. VAT
5
Rondelle fer plate
AP8152018
$3,65 Unit Price incl. VAT
6
Axe fixation biellette
AP8121627
$24,14 Unit Price incl. VAT
7
Resin bush
AP8102538
$3,65 Unit Price incl. VAT
8
Silent-block
AP8144598
$55,19 Unit Price incl. VAT
9
Vis
AP8150345
$3,65 Unit Price incl. VAT
10
Entretoise
AP8121628
$12,36 Unit Price incl. VAT
11
Rondelle
AP8150020
$0,08 Unit Price incl. VAT
12
Ecrou autobloqu.
AP8152301
$0,59 Unit Price incl. VAT
13
Axe fixation châssis
AP8121528
$15,31 Unit Price incl. VAT
14
Douille biellette
AP8121562
$18,12 Unit Price incl. VAT
15
Pivot support moteur;
AP8121598
$12,45 Unit Price incl. VAT
16
Anti-theft pin
AP8146752
Not Available

Find the detailed Crankshaft assy APRILIA diagram on this page. This exploded view allows you to identify the various components you need to maintain your machine and quickly find their original APRILIA part number.


The diagrams are not contractually binding. If you have any doubts, our professionals are available to answer your questions. When adding a part to your cart, make sure to order the desired quantity. The unit price shown is the price for each reference at a quantity of 1.
