1
Engine displacement
1100
2
Model
TUONO
3
Year
2017
4
Trim
Tuono V4 1100 RR E4 ABS
5
Parts Catalog
Electrical system I
6
Parts Diagram
Parts Catalog
Oil radiator
by
Front master cilinder
Electrical system I
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
7
6
6
5
4
3
2
1
1
Horn
890979
$26,82 Unit Price incl. VAT
2
Screw w/ flange M6x12
AP8152277
$0,25 Unit Price incl. VAT
3
Spring plate M6
254485
$0,34 Unit Price incl. VAT
4
Voltage regulator
B043488
$314,97 Unit Price incl. VAT
5
Hex socket screw M6x30
AP8152128
$0,34 Unit Price incl. VAT
6
Washer 6,6x18*
AP8150179
$0,08 Unit Price incl. VAT
7
T bush *
AP8121075
$3,65 Unit Price incl. VAT
8
Self-locking nut M6
AP8152299
$0,34 Unit Price incl. VAT
9
Screw w/ flange M6x20
AP8152279
$0,51 Unit Price incl. VAT
10
Bush
AP8121991
$5,20 Unit Price incl. VAT
11
Main wiring harness
2D000302
$1 115,84 Unit Price incl. VAT
12
Relay 12V-30A
AP8224462
$14,17 Unit Price incl. VAT
13
Rubber spacer *
AP8220283
$0,75 Unit Price incl. VAT
14
Sensor support
858916
$1,62 Unit Price incl. VAT
15
Instrument support
890760
$0,51 Unit Price incl. VAT
16
Horn support
2B001765
$15,98 Unit Price incl. VAT
17
Hex socket screw M5x9
AP8150500
$1,53 Unit Price incl. VAT
18
Clip M5
AP8102375
$0,69 Unit Price incl. VAT
19
Hex socket screw M5x9
AP8150500
$1,53 Unit Price incl. VAT
20
Stop switch
2D000325
$45,09 Unit Price incl. VAT
21
Maintenance switch
2B003519
$5,38 Unit Price incl. VAT
22
Turn ind.harness
2D000178
$18,44 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
