1
Engine displacement
125
2
Model
ETX
3
Year
1998
4
Trim
ETX
5
Parts Catalog
Lights
6
Parts Diagram
Parts Catalog
Rear brake II
by
Electrical system I
Lights
1
2
3
3
3
3
4
4
4
4
5
6
7
8
9
9
9
9
10
10
11
11
11
12
12
12
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
1
Taillight
AP8112531
$214,56 Unit Price incl. VAT
2
Headlight lens
AP8124533
Not Available
3
Rear turn indicator
AP8112922
Not Available
4
Turn indicator lens
AP8112756
$2,97 Unit Price incl. VAT
5
Taillight lens
AP8112633
Not Available
6
Lampholder
AP8124475
Not Available
7
Front headlight guard
AP8124532
Not Available
8
Headlight
AP8112662
Not Available
8
Headlight
AP8124482
Not Available
9
T bush
AP8121795
$3,38 Unit Price incl. VAT
10
Hex socket screw M6x20
AP8150044
$3,65 Unit Price incl. VAT
11
Low self-locking nut M6
AP8150115
$13,79 Unit Price incl. VAT
12
Washer 6,4x12,5*
AP8150178
$0,34 Unit Price incl. VAT
13
Hex socket screw M6x25
AP8150165
$3,65 Unit Price incl. VAT
14
Self-locking nut M6
AP8152299
$0,34 Unit Price incl. VAT
15
Washer 6,6x18x1,6*
AP8150015
$0,16 Unit Price incl. VAT
16
Nut M4
AP8150204
$0,51 Unit Price incl. VAT
17
Washer 4,3x12x1
AP8150011
$0,25 Unit Price incl. VAT
18
Light frame
AP8139296
Not Available
19
Screw 3x15*
AP8152114
Not Available
20
screw
AP8124554
Not Available
21
Washer 10x5,3x1*
AP8120591
$0,25 Unit Price incl. VAT
22
Circlip 3,2
AP8124553
Not Available
23
Conic Pawl
AP8112716
Not Available
24
Light guard decal
AP8147906
Not Available
25
Headlight bush
AP8121718
$3,38 Unit Price incl. VAT
The diagrams are provided for reference only. If in doubt, our specialists are available to answer your questions. When adding a part to your cart, please make sure to select the desired quantity. The unit price shown is the price for one unit of each part number.
